PI TAPE Model PM5 - 1200mm - 1500mm Range Outside Diameter Measuring Tape - 1095 Steel
$306.24
Ships in 2–4 Weeks
In stock
1
Save this product for later
Customer reviews
Reviews only from verified customers
No reviews yet. You can buy this product and be the first to leave a review.
PI TAPE Model PM5 - 1200mm - 1500mm Range Outside Diameter Measuring Tape - 1095 Steel
Product Details
The Pi Tape PM5 outside diameter tape measures the outside diameter of shafts, pipe, rolls, tanks and other cylinders from 1200 to 1500 mm directly. Its scale is graduated in units of π, so it reads the diameter rather than the circumference, and a vernier gives the fine reading.
| Model · Type | PM5 · Outside diameter (O.D.) |
| Measuring range | 1200 to 1500 mm |
| Reading · Accuracy | Metric, vernier to 0.01 mm · ±0.03 mm |
| Material | 1095 spring steel. Pi Tape’s standard steel, for dry, non-corrosive conditions. |
| Tape width · thickness | 1/4″ (6.35 mm) gage, 1/2″ (12.7 mm) body · 0.010″ (0.25 mm) |
| Calibration | Calibration report traceable through NIST to SI units, from Pi Tape’s ISO/IEC 17025 accredited lab |
| Made by | Pi Tape Texas, LLC, Tyler, Texas, USA |
Built to your order by Pi Tape: typically ships in 2–4 weeks. Jealco is an authorized Pi Tape distributor.
Using it: clean the tape and the part, wrap the tape square to the axis of the part, read the main scale at the vernier zero, then add the vernier line that lines up exactly. Pi Tape’s instruction sheet comes with the tape.
Other sizes and recertification: larger, special and custom tapes are quoted to order. Pi Tape also recertifies tapes with a new calibration report; ask us to arrange it.
