PI TAPE Model PM10SS - 2700mm - 3000mm Range Outside Diameter Measuring Tape - Stainless Steel
Home/Store/Precision Diameter Measuring Tapes/Outside Diameter Measuring Tapes/MM/716 Stainless Steel
$661.22
Ships in 2–4 Weeks
In stock
1
Save this product for later
Customer reviews
Reviews only from verified customers
No reviews yet. You can buy this product and be the first to leave a review.
PI TAPE Model PM10SS - 2700mm - 3000mm Range Outside Diameter Measuring Tape - Stainless Steel
Home/Store/Precision Diameter Measuring Tapes/Outside Diameter Measuring Tapes/MM/716 Stainless Steel
Product Details
The Pi Tape PM10SS outside diameter tape measures the outside diameter of shafts, pipe, rolls, tanks and other cylinders from 2700 to 3000 mm directly. Its scale is graduated in units of π, so it reads the diameter rather than the circumference, and a vernier gives the fine reading.
| Model · Type | PM10SS · Outside diameter (O.D.) |
| Measuring range | 2700 to 3000 mm |
| Reading · Accuracy | Metric, vernier to 0.01 mm · ±0.03 mm |
| Material | 716 stainless steel. For corrosive, wet, washdown, marine and food environments. |
| Tape width · thickness | 1/4″ (6.35 mm) gage, 1/2″ (12.7 mm) body · 0.010″ (0.25 mm) |
| Calibration | Calibration report traceable through NIST to SI units, from Pi Tape’s ISO/IEC 17025 accredited lab |
| Made by | Pi Tape Texas, LLC, Tyler, Texas, USA |
Built to your order by Pi Tape: typically ships in 2–4 weeks. Jealco is an authorized Pi Tape distributor.
Using it: clean the tape and the part, wrap the tape square to the axis of the part, read the main scale at the vernier zero, then add the vernier line that lines up exactly. Pi Tape’s instruction sheet comes with the tape.
Other sizes and recertification: larger, special and custom tapes are quoted to order. Pi Tape also recertifies tapes with a new calibration report; ask us to arrange it.
All Pi Tape models and ranges → · Pi Tape guide on jealco.com →
