The Ampco Safety IM-20 Deluxe Insulated Tool Kit is a 17-piece set built for electrical maintenance work in hazardous environments. Every tool is manufactured from Ampco's beryllium copper alloy — non-sparking, non-magnetic, and corrosion resistant — and individually insulated to 1,000V for protection against accidental contact with energized conductors. The kit covers the most common hand tool needs: adjustable and box-end wrenches, combination and diagonal cutting pliers, groove joint pliers, Phillips and standard screwdrivers, a 3/8" drive ratchet with sockets and extension, and a scratch brush, all organized in a tool box with a removable tray. Made in the USA.

Non-Sparking · Non-Magnetic · Corrosion-Resistant · Made in the USA

Kit includes:

• Adjustable Combination Wrench, 8": IP-31
• Lineman's / Side Cutting Pliers, 8-1/2": IP-35
• Diagonal Cutting Pliers, 7": IP-36
• Groove Joint Pliers, 10": IP-39
• #2 Phillips Screwdriver: IS-1099
• Standard Screwdriver, 5/16" Tip: IS-49
• Standard Socket, 6-Point, 3/8" Drive, 7/16": ISS-3/8D7/16
• Standard Socket, 6-Point, 3/8" Drive, 1/2": ISS-3/8D1/2
• Standard Socket, 6-Point, 3/8" Drive, 9/16": ISS-3/8D9/16
• Ratchet Wrench, 3/8" Drive: IW-142R
• Extension Bar, 3/8" Drive: IWE-3/8X6
• Adjustable Wrench, 8": IW-71
• Adjustable Wrench, 10": IW-72
• Single Box End Wrench, 12-Point, 7/16": IWSB-7/16
• Single Box End Wrench, 12-Point, 1/2": IWSE-1/2
• Single Box End Wrench, 12-Point, 9/16: IWSE-9/16
• Toothbrush Style Scratch Brush with Wooden Handle: TB-10
• Tool Box: M-49-BO

Specifications: Weight 11 lbs · Dimensions 16" × 9-1/4" × 8" · UPC 702535882129

Frequently Asked Questions

Is the entire kit rated to 1,000V?

All tools in the IM-20 kit are individually insulated and rated to 1,000V AC/DC — with one exception: the adjustable wrenches are not 1,000V rated. For live electrical work where every tool in contact with the circuit must be fully rated, confirm the specific tool requirements for your application before use.

What makes these tools safe for use around flammable atmospheres?

Every tool in the IM-20 kit is manufactured from Ampco beryllium copper (BeCu) alloy, which does not produce friction sparks when struck against hard surfaces. This makes the kit appropriate for maintenance work in oil and gas, petrochemical, and other classified hazardous locations where both ignition risk and electrical shock hazard are present simultaneously.

What tools are included in the 17-piece set?

The kit includes an 8" adjustable combination wrench, lineman's and diagonal cutting pliers, groove joint pliers, Phillips and standard screwdrivers, a 3/8" drive ratchet with 7/16", 1/2", and 9/16" six-point sockets and extension bar, three single box-end wrenches (7/16", 1/2", 9/16"), and a scratch brush — all stored in a tool box with a removable tray.

Where is the IM-20 kit manufactured?

The IM-20 is made in the USA. The sliding bar for the extension is manufactured in the USA using components sourced from the United Kingdom.
